F59D1G161MB-45TG2M
F59D1G161MB-45TG2M is 1.8V NAND Flash Memory manufactured by Elite Semiconductor Microelectronics Technology.
- Part of the F59D1G81MB-45TG2M comparator family.
- Part of the F59D1G81MB-45TG2M comparator family.
ESMT
Flash
Features
- Voltage Supply: 1.8V (1.7 V ~ 1.95V)
- Organization x8:
- Memory Cell Array: (128M + 4M) x 8bit
- Data Register: (2K + 64) x 8bit x16:
- Memory Cell Array: (64M + 2M) x 16bit
- Data Register: (1K + 32) x 16bit
- Automatic Program and Erase x8:
- Page Program: (2K + 64) Byte
- Block Erase: (128K + 4K) Byte x16:
- Page Program: (1K + 32) Word
- Block Erase: (64K + 2K) Word
- Page Read Operation x8
- Page Size: (2K + 64) Byte (x8)
- Random Read: 25us (Max.)
- Serial Access: 45ns (Min.) x16 -Page Size: (1K + 32) Word (x16)
- Memory Cell: 1bit/Memory Cell
- Fast Write Cycle Time x8
- Program time: 300us (Typ.)
- Block Erase time: 4ms (Typ.)
- mand/Address/Data...
