FMMT491
TRANSISTOR (NPN)
1．BASE 2．EMITTER 3．COLLECTOR
SOT-23
MAXIMUM RATINGS (TA=25℃ unless otherwise noted)
Symbol
Parameter
VCBO VCEO
Collector-Base Voltage Collector-Emitter Voltage
VEBO
Emitter-Base Voltage
Collector Current -Continuous
Collector Power Dissipation
Tj
Junction Temperature
Tstg
Storage Temperature
Value 40 25 5 1.8 0.3 150
-55-150
ELECTRICAL CHARACTERISTICS (Tamb=25℃ unless otherwise specified)
Parameter
Symbol
Test conditions
Units V V V A W ℃ ℃
MAX UNIT
Collector-base breakdown voltage
V(BR)CBO IC= 100μA, IE=0
Collector-emitter breakdown voltage
V(BR)CEO IC= 0.1m A, IB=0
Emitter-base breakdown voltage
V(BR)EBO IE=100μA, IC=0
Collector cut-off current
ICBO
VCB=40V,...
