Overview: www.fairchildsemi.com MC78XX/LM78XX/MC78XXA 3-Terminal 1A Positive Voltage.
This datasheet includes multiple variants, all published together in a single manufacturer document.
| Part number | MC7805A |
|---|---|
| Manufacturer | Fairchild (now onsemi) |
| File Size | 225.42 KB |
| Description | 3-Terminal 1A Positive Voltage Regulator |
| Datasheet | MC7805A MC7805 Datasheet (PDF) |
|
|
|
The MC78XX/LM78XX/MC78XXA series of three terminal positive regulators are available in the TO-220/D-PAK package and with several fixed output voltages, making them useful in a wide range of applications.
Each type employs internal current limiting, thermal shut down and safe operating area protection, making it essentially indestructible.
If adequate heat sinking is provided, they can deliver over 1A output current.
