ESD5Z15 Overview
SMD Transient Voltage Suppressor For ESD Protection ESD5Z SERIES Formosa MS Surface Mount Uni-Directional TVS For ESD Protection Diode 2.5V-15V.
ESD5Z15 Key Features
- Small body outline dimensions
- Low body height
- Stand off voltage: 2.5V,3.3V,5.0V,7.0V,12V,15V
- Low leakage
- Response time is typically <1ns
- Provide transient protection
- Lead-free parts meet RoHS requirements
- Suffix "-H" indicates Halogen-free part, ex.ESD5Z2.5-H
