1SS184 - Surface mount switching diode

Key Features

  • Low forward voltage VF=0.9V(typ). Pb Lead-free.
  • Small total capacitance.
  • Fast reverse recovery time:trr=1.6ns(typ). 1SS184.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
1SS184 Silicon Epitaxial Planar Type Diode Toshiba Semiconductor
1SS184 SILICON EPITAXIAL PLANAR DIODE EIC
1SS184 SWITCHING DIODE JCET
1SS184 SURFACE MOUNT FAST SWITCHING DIODE WON-TOP
1SS184 Ultra High Speed Switching Eris

Other Datasheets by Galaxy Microelectronics

Part Number Description
1SS187 Surface mount switching diode
1SS141 SMALL SIGNAL SWITCHING DIODES
1SS144 SMALL SIGNAL SWITCHING DIODES
1SS145 SMALL SIGNAL SWITCHING DIODES
1SS146 SMALL SIGNAL SWITCHING DIODES

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Production specification Surface mount switching diode FEATURES  Low forward voltage VF=0.9V(typ). Pb Lead-free  Small total capacitance.  Fast reverse recovery time:trr=1.6ns(typ). 1SS184 APPLICATIONS  High speed switching application. SOT-23 ORDERING INFORMATION Type No.
