2SC1623 - Silicon Transistor

Galaxy Microelectronics

Key Features

High DC current gain:hFE=200TYP (VCE=6.0V,IC=1.0mA).
High Voltage:VCEO=50V.
MSL 1.

2SC1623 silicon transistor by Galaxy Microelectronics - Datasheet Preview

Datasheet Details

Part number	2SC1623
Manufacturer	Galaxy Microelectronics
File Size	214.52 KB
Description	Silicon Transistor
Datasheet	2SC1623 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
2SC1623	NPN Transistor	NEC
2SC1623	AMPLIFIER NPN TRANSISTOR	UTC
2SC1623	NPN Transistor	INCHANGE
2SC1623	NPN Transistor	MCC
2SC1623	NPN Transistor	Weitron Technology

Other Datasheets by Galaxy Microelectronics

Part Number	Description
2SC1623W	NPN Transistor
2SC1654	Silicon Epitaxial Planar Transistor
2SC1766	NPN Transistor
2SC1815	Silicon Epitaxial Planar Transistor
2SC2073	NPN Triple Didduesd Planar Silicon Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

Production specification Silicon Epitaxial Planar Transistor FEATURES  High DC current gain:hFE=200TYP (VCE=6.0V,IC=1.0mA).  High Voltage:VCEO=50V.  MSL 1. APPLICATIONS Pb Lead-free  NPN Silicon Epitaxial Planar Transistor.  Audio frequency general purpose amplifier. ORDERING INFORMATION Type No. Marking 2SC1623 L4/L5/L6/L7 2SC1623 SOT-23 Package Code SOT-23 MAXIMUM RATING @ Ta=25℃ unless otherwise specified Symbol Parameter Value VCBO VCEO VEBO IC PC Tj,Tstg Collector-Base Voltage Collector-Emitter Voltage Emitter-Base Voltage Collector Current -Continuous Collector Dissipation Junction and Storage Temperature 60 50 5 100 200 -55 to +150 Units V V V mA mW ℃ C018 Rev.A www.gmesemi.
