2SC4097 - Silicon Epitaxial Planar Transistor

Key Features

  • z Excellent hFE linearity. z Power dissipation:PCM=200mW Pb Lead-free Production specification 2SC4097.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
2SC4097 Medium Power Transistor Rohm
2SC4097 NPN Plastic-Encapsulate Transistor SeCoS
2SC4097-P NPN Silicon Epitaxial Transistors MCC
2SC4097-Q NPN Silicon Epitaxial Transistors MCC
2SC4097-R NPN Silicon Epitaxial Transistors MCC

Other Datasheets by Galaxy Microelectronics

Part Number Description
2SC4003 NPN Epitaxial Planar Silicon Transistor
2SC4081 Silicon Epitaxial Planar Transistor
2SC4102 Silicon Transistor
2SC4115 NPN Epitaxial Planar Silicon Transistor
2SC4116 Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Silicon Epitaxial Planar Transistor FEATURES z Excellent hFE linearity. z Power dissipation:PCM=200mW Pb Lead-free Production specification 2SC4097 APPLICATIONS z NPN Silicon Epitaxial Planar Transistor. ORDERING INFORMATION Type No. Marking 2SC4097 CP/CQ/CR SOT-323 Package Code SOT-323 MAXIMUM RATING @ Ta=25℃ unless otherwise specified Symbol Parameter Value VCBO Collector-Base Voltage 40 VCEO Collector-Emitter Voltage 32 VEBO Emitter-Base Voltage 5 IC Collector Current -Continuous 500 ICM Peak Collector Current 500 IBM Peak Base Current 10 PC Collector Dissipation 250 Tj,Tstg Junction and Storage Temperature -55 to +150 Units V V V mA mA mA mW ℃ F003 Rev.A www.gmicroelec.
