Galaxy Century Microelectronics BCW72
NPN General Purpose Amplifier
| Part No. | BCW72 |
|---|---|
| Datasheet | BCW72 Download |
| Manufacturer | Galaxy Century Microelectronics |
| Description | NPN General Purpose Amplifier |
| Buy | Stock & Price |
FEATURES
● Super Mini Packaged Transistor for Hybrid Circuits.APPLICATIONS
● General purpose switching and amplification.● For Complementary with PNP Type BCW69/70. Product Specification BCW71/BCW72 ORDERING INFORMATION Type No. Marking BCW71 K1 BCW72 K2 SOT-23 Package Code SOT-23 SOT-23 MAXIMUM RATING @ Ta=25℃ unless otherwise specified Symbol Parameter Value Unit VCBO Collector-Base Voltage 50 V VCEO Collector-Emitter Voltage 45 V VEBO Emitter-Base Voltage 5 V IC Collector Current -Continuous 100 mA PD Total power Dissipation 350 mW Tj,Tstg Junction and Storage Temperature -65 to +150 ℃ STM0088A: December 2018 1 Product Specification NPN General Purpose Amplifier BCW71/BCW72
ELECTRICAL CHARACTERISTICS
@ Ta=25℃ unless otherwise specified Parameter Symbol Test conditions MIN Typ MAX UNIT Collector-base breakdown voltage V(BR)CBO IC=10μA IE=0 50 V Collector-emitter breakdown voltage V(BR)CEO IC=2mA IB=0 45 V Emitter-base breakdown voltage Collector cut-off current DC current gain BCW7...
