DTA124EUA - Digital Transistor

Download the DTA124EUA datasheet PDF. This datasheet also covers the DTA114EUA variant, as both devices belong to the same digital transistor family and are provided as variant models within a single manufacturer datasheet.

Key Features

  • Pb z Epitaxial planar die construction. Lead-free z Complementary NPN types available(DTA). z Built-in biasing resistors,R1=R2 z Also available in lead free version.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (DTA114EUA-GME.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
DTA124EUA PNP Digital transistors JinYu
DTA124EUA PNP Digital Transistor JCET
DTA124EUA PNP Digital Transistor MCC
DTA124EUA DIGITAL TRANSISTORS Rectron
DTA124EUA Digital Transistor Rohm

Other Datasheets by Galaxy Microelectronics

Part Number Description
DTA124ECA Digital Transistor
DTA124EE Digital Transistor
DTA124TCA Digital Transistor
DTA114ECA Digital Transistor
DTA114EUA Digital Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Production specification Digital Transistor DTA(R1=R2 SERIES)UA FEATURES Pb z Epitaxial planar die construction. Lead-free z Complementary NPN types available(DTA). z Built-in biasing resistors,R1=R2 z Also available in lead free version. APPLICATIONS z The NPN style digital transistor. ORDERING INFORMATION Type No. Marking DTA114EUA DTA143EUA DTA124EUA DTA144EUA 14 13 15 16 SOT-323 Package Code SOT-323 SOT-323 SOT-323 SOT-323 MAXIMUM RATING @ Ta=25℃ unless otherwise specified Symbol Parameter VCC VIN IO IC(Max.
