MMBT2907 - PNP General Purpose Amplifier

Key Features

  • z Epitaxial planar die construction. z Ideal for medium power amplification and switching. Pb Lead-free MMBT2907.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MMBT2907 PNP Transistor MIC
MMBT2907 PNP GENERAL PURPOSE AMPLIFIER ART CHIP
MMBT2907 SWITCHING TRANSISTOR HOTTECH
MMBT2907 PNP Transistor Samsung
MMBT2907 PNP General Purpose Amplifier Fairchild

Other Datasheets by Galaxy Microelectronics

Part Number Description
MMBT2907A PNP General Purpose Amplifier
MMBT2907AT PNP Transistor
MMBT2222 NPN General Purpose Amplifier
MMBT2222A NPN Amplifier
MMBT2222AT NPN SWITCHING TRANSISTOR

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Production specification PNP General Purpose Amplifier FEATURES z Epitaxial planar die construction. z Ideal for medium power amplification and switching. Pb Lead-free MMBT2907 APPLICATIONS z This device is designed as a general purpose amplifier and switching. ORDERING INFORMATION Type No. Marking MMBT2907 M2B SOT-23 Package Code SOT-23 MAXIMUM RATING @ Ta=25℃ unless otherwise specified Symbol Parameter Value VCBO VCEO VEBO IC PD RθJA Collector-Base Voltage Collector-Emitter Voltage Emitter-Base Voltage Collector Current -Continuous Total Device Dissipation Thermal resistance,Junction to ambient -60 -40 -5 -600 350 357 Tj,Tstg Junction and Storage Temperature -55 to +150 Unit V V V mA mW ℃/W ℃ C090 Rev.A www.gmicroelec.
