SJM65R040FRU Datasheet | Galaxy Microelectronics

Features - Best-in-class RDS(on) and QG - Ultra-fast body diode - Excellent thermal behavior - HBM: JESD22-A114-B: 2 - Product validation acc. JEDEC Standard - Ro HS pliant with Halogen-free Applications - Soft switching applications - EV charging - Solar invertor - Server Mechanical Data - Case: TO-247 - Molding pound: UL Flammability Classification Rating 94V-0 - Terminals: Matte tin-plated leads; solderability-per MIL-STD-202, Method 208 TO-247 Ordering Information Part Number SJM65R040FRU Package TO-247 Shipping Quantity 30 pcs / Tube Marking Code SJM65R040FRU Maximum Ratings (@ TC = 25°C unless otherwise specified) Parameter Drain-to-Source Voltage Gate-to-Source Voltage Continuous Drain Current (TC = 25°C) Continuous Drain Current (TC = 100°C) Pulsed Drain Current (tp = 10μs, TC = 25°C) Single Pulse Avalanche Energy - 2 Power Dissipation (TC = 25°C) Operating Junction Temperature Range Storage Temperature Range Symbol VDSS VGSS IDM EAS PD TJ TSTG Value 650 ±30 70 45 280 2500 500 -55 ~ +150 -55 ~ +150 Unit V V A A A m J W °C °C Thermal Characteristics Parameter Thermal Resistance Junction-to-Case Thermal Resistance Junction-to-Air MTM1469A: May 2024 [2.0] Symbol RθJC RθJA Min. - .gmesemi. Typ. 0.2 - Max. 0.25 40 Unit °C/W...
