Galaxy Century Microelectronics TBL2300
N-Channel Enhancement Mode MOSFET
| Part No. | TBL2300 |
|---|---|
| Datasheet | TBL2300 Download |
| Manufacturer | Galaxy Century Microelectronics |
| Description | N-Channel Enhancement Mode MOSFET |
| Buy | Stock & Price |
FEATURES
● High-speed switching● Drive circuits can be simple
● Parallel use is easy
● Halogen free
● Qualified to AEC-Q101 standards for high reliability Typical
APPLICATIONS
● Power management in note book● Switching application
● Battery powered system
● Load switch TBL2300 SOT-23 TBL2300-3L SOT-23-3L
MECHANICAL DATA
● Case: SOT-23, SOT-23-3L● Molding Compound: UL Flammability Classification Rating 94V-0
● Terminals: Matte tin-plated leads; solderability-per MIL-STD-202, Method 208 Ordering Information Part Number TBL2300 TBL2300-3L Package SOT-23 SOT-23-3L Shipping Quantity 3000 pcs / Tape & Reel 3000 pcs / Tape & Reel Marking Code 2300 2300
MAXIMUM RATINGS
(@ TA = 25°C unless otherwise specified) Parameter Drain-to-Source Voltage Gate-to-Source Voltage Continuous Drain Current (TA = 25°C) *1 Continuous Drain Current (TA = 70°C) *1 Pulsed Drain Current (tp = 10μs, TA = 25°C) Single Pulse Avalanche Energy *3 Power Dissipation (TA = 25°C) *1 Operating Junction Temperature Range St...
