Datasheet Details
| Part number | IRF9540 |
|---|---|
| Manufacturer | Harris |
| File Size | 53.19 KB |
| Description | P-Channel Power MOSFET |
| Datasheet | IRF9540-Harris.pdf |
|
|
Overview: Semiconductor July 1998 IRF9540, IRF9541, IRF9542, IRF9543, RF1S9540, RF1S9540SM -15A and -19A, -80V and -100V, 0.20 and 0.
| Part number | IRF9540 |
|---|---|
| Manufacturer | Harris |
| File Size | 53.19 KB |
| Description | P-Channel Power MOSFET |
| Datasheet | IRF9540-Harris.pdf |
|
|
|
• -15A and -19A, -80V and -100V • rDS(ON) = 0.20Ω and 0.30Ω • Single Pulse Avalanche Energy Rated • SOA is Power Dissipation Limited • Nanosecond Switching Speeds • Linear Transfer Characteristics • High Input Impedance • Related Literature - TB334 “Guidelines for Soldering Surface Mount Components to PC Boards” Ordering Information PART NUMBER PACKAGE BRAND These are P-Channel enhancement mode silicon gate power field effect transistors.
They are advanced power MOSFETs designed, tested, and guaranteed to withstand a specified level of energy in the breakdown avalanche mode of operation.
All of these power MOSFETs are designed for applications such as switching regulators, switching convertors, motor drivers, relay drivers, and drivers for high power bipolar switching transistors requiring high speed and low gate drive power.
