Datasheet Summary
Touch I/O Flash MCU with LCD/LED Driver
BS82C16CA/BS82D20CA
Revision: V1.40 Date: January 26, 2026
BS82C16CA/BS82D20CA Touch I/O Flash MCU with LCD/LED Driver
Features
CPU Features
- Operating voltage
- fSYS=8MHz: 1.8V~5.5V
- fSYS=12MHz: 2.7V~5.5V
- fSYS=16MHz: 3.3V~5.5V
- Up to 0.25μs instruction cycle with 16MHz system clock at VDD=5V
- Power down and wake-up functions to reduce power consumption
- Oscillator types
- Internal High Speed 8/12/16MHz RC
- HIRC
- External Low Speed 32.768kHz Crystal
- LXT
- Internal Low Speed 32kHz RC
- LIRC
- Multi-mode operation: FAST, SLOW, IDLE and SLEEP
- Fully integrated internal oscillators require no external ponents
- All instructions executed...
