HT7321-7 - 30V 250mA TinyPower LDO

General Description

The HT73xx-7 is a low power high voltage series of regulators implemented in CMOS technology which has the advantages of low voltage drop and low quiescent current.

They allow input voltages as high as 30V and are available with several fixed output voltages ranging from 2.1V to 5.0V.

Key Features

  • Low power consumption.
  • Low voltage drop.
  • Low temperature coefficient.
  • High input voltage.
  • up to 30V.
  • Output voltage accuracy: tolerance ±2%.
  • Over current protection.
  • Over temperature protection.
  • Chip enable/disable function.
  • Package types: 8-pin SOP-EP, SOT89-3 and TO92-3.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
HT7005L LCD HYES Optoelectronics
HT7017 High-precision single-phase metering chip HiTrendtech
HT7020 three-port low voltage detector UMW
HT7022 three-port low voltage detector UMW
HT7024 three-port low voltage detector UMW

Other Datasheets by Holtek Semiconductor

Part Number Description
HT7321-1 250mA TinyPower LDO
HT7321-2 30V 250mA TinyPower LDO
HT7321-3 250mA TinyPower LDO
HT7323-1 250mA TinyPower LDO
HT7323-2 30V 250mA TinyPower LDO

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
HT73xx-7 30V, 250mA TinyPowerTM LDO with Protections Features • Low power consumption • Low voltage drop • Low temperature coefficient • High input voltage – up to 30V • Output voltage accuracy: tolerance ±2% • Over current protection • Over temperature protection • Chip enable/disable function • Package types: 8-pin SOP-EP, SOT89-3 and TO92-3 Applications • Battery-powered equipment • Communication equipment • Audio/Video equipment General Description The HT73xx-7 is a low power high voltage series of regulators implemented in CMOS technology which has the advantages of low voltage drop and low quiescent current. They allow input voltages as high as 30V and are available with several fixed output voltages ranging from 2.1V to 5.0V.
