HT7330-7
Features
- Low power consumption
- Low voltage drop
- Low temperature coefficient
- High input voltage
- up to 30V
- Output voltage accuracy: tolerance ±2%
- Over current protection
- Over temperature protection
- Package type: 3-pin SOT89
Applications
- Battery-powered equipment
- munication equipment
- Audio/Video equipment
General Description
The HT73xx-7 is a low power high voltage series of regulators implemented in CMOS technology which has the advantages of low voltage drop and low quiescent current. They allow input voltages as high as 30V and are available with several fixed output voltages ranging from 2.1V to 5.0V.
An internal over-current protection circuit prevents the device from damage even if the output is shorted to ground. An over-temperature protection circuit ensures the device junction temperature will not exceed a temperature of 150°C.
Selection Table
Part No. HT7321-7 HT7323-7 HT7325-7 HT7327-7 HT7330-7 HT7333-7 HT7336-7 HT7340-7 HT7344-7 HT7350-7
Output...
