Holtek Semiconductor HT7130-1
The HT71xx-1 series is a set of three-terminal low power high voltage regulators implemented in CMOS technology. They allow input voltages as high as 30V. They are available with several fixed output voltages ranging from 2.1V to 5.0V.| Part No. | HT7130-1 |
|---|---|
| Datasheet | HT7130-1 Download |
| Manufacturer |  Holtek Semiconductor |
| Description | 30mA Low Power LDO |
| Buy | Stock & Price |
FEATURES
● Low power consumption● Low voltage drop
● Low temperature coefficient
● High input voltage (up to 30V)
● Output voltage accuracy: tolerance ±3%
● Package types: 3-pin SOT89 and 5-pin SOT23
APPLICATIONS
● Battery-powered equipment● Communication equipment
● Audio/Video equipment
GENERAL DESCRIPTION
They allow input voltages as high as 30V. CMOS technology ensures low voltage drop and low quiescent current. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain variable voltages and currents. Selection Table Part No. HT7121-1 HT7123-1 HT7125-1 HT7127-1 HT7130-1 HT7133-1 HT7136-1 HT7144-1 HT7150-1 Output Voltage 2.1V 2.3V 2.5V 2.7V 3.0V 3.3V 3.6V 4.4V 5.0V Note: ″xx″ stands for output voltages. Package Marking SOT89 SOT23-5 71xx-1 (for SOT89) 1xx1 (for SOT23-5) Rev. 2.71 3 December 03, 2025 Block Diagram V IN HT71xx-1 30V, 30mA Low Power LDO VO UT V re f GND Pin Assignment TO 92 7 1 x x -1 / 7 1 x x A -1 F r o n t...
