HT67F2567 Description
The HT67F2567 is a Flash Memory 8-bit high performance RISC architecture microcontrollers, designed for applications that EPD display products. Offering users the convenience of Flash Memory multi-programming.
HT67F2567 Key Features
- Operating voltage
- fSYS=4MHz: 1.8V~5.5V
- fSYS=8MHz: 2.2V~5.5V
- fSYS=12MHz: 2.7V~5.5V
- Up to 0.33μs instruction cycle with 12MHz system clock at VDD=5V
- Power down and wake-up functions to reduce power consumption
- Oscillator types
- Internal High Speed 4/8/12MHz RC Oscillator
- External Low Speed 32.768kHz Crystal
- Internal Low Speed 32kHz RC Oscillator- LIRC, for power on reset and LVD/LVR functions only
