Datasheet Details
| Part number | 6N136 |
|---|---|
| Manufacturer | ISOCOM |
| File Size | 2.29 MB |
| Description | Optocoupler |
| Datasheet | 6N136 6N135 Datasheet (PDF) |
|
|
Overview: ISO PONENTS 6N135, 6N136, ICPL4502, ICPL4503.
This datasheet includes multiple variants, all published together in a single manufacturer document.
| Part number | 6N136 |
|---|---|
| Manufacturer | ISOCOM |
| File Size | 2.29 MB |
| Description | Optocoupler |
| Datasheet | 6N136 6N135 Datasheet (PDF) |
|
|
|
The 6N135, 6N136, ICPL4502 and ICPL4503 devices each consists of an infrared emitting diode, optically coupled to a high speed photo detector transistor.
A separate connection for the photodiode bias and output-transistor collector increases the speed by several orders of magnitude over conventional phototransistor couplers by reducing the base-collector capacitance of the input transistor.
