BAT14...
Silicon Schottky Diode
DBS mixer applications up to 12 GHz Low noise figure Low barrier type
BAT14-03W
1
2
ESD: Electrostatic discharge sensitive device, observe handling precaution!
Type BAT14-03W Package SOD323 Configuration single LS(nH) Marking 1.8 O/white
Maximum Ratings at TA = 25°C, unless otherwise specified Parameter Symbol VR IF Ptot Tj Top Tstg Symbol RthJS Value Unit
Diode reverse voltage Forward current Total power dissipation
TS 85 °C
4 90 100 150 -55 ... 125 -55 ... 150
V mA mW °C
Junction temperature Operating temperature range Storage temperature
Thermal Resistance Parameter
Value
Unit
Junction - soldering point1)
1For
690
K/W
calculation of RthJA please refer to Application Note Thermal Resistance
1
Feb-03-2003
BAT14...
