MAXIMUM RATINGS
at TA = 25°C, unless otherwise specified Parameter Symbol Diode reverse voltage VR Forward current IF Total power dissipation Ptot BAR63-02L, TS ≤ 118°C BAR63-02V, -02W, BAR63-03W, TS ≤ 115°C BAR63-04...BAR63-06, TS ≤ 55°C BAR63-04S, TS ≤ 115°C BAR63-04W...BAR63-06W, TS ≤ 105°C Junction temperature Tj Operating temperature range Top Storage temperature Tstg Thermal Resistance Parameter Junction - soldering point1) BAR63-02L BAR63-02V, BAR63-02W BAR63-03W BAR63-04...BAR63-06 BAR63-04S BAR63-04W...BAR63-06W Symbol RthJS Value 50 100 250 250 250 250 250 150 -55 ... 125 -55 ... 150 Value ≤ 125 ≤ 140 ≤ 155 ≤ 380 ≤ 180 ≤ 180 Unit V mA mW °C Unit K/W ELECTRICAL CHARACTERISTICS
at TA = 25°C, unless otherwise specified Parameter Symbol Values Unit min. typ. max. DC Characteristics Breakdown voltage I(BR) = 5 µA Reverse current VR = 35 V Forward voltage IF = 100 mA V(BR) IR VF 50 - -V - - 10 nA - 0.95 1.2 V 1For calculation of RthJA please refer to the Technical Information 2 2011-07-18 BAR63...
