N116BGE-L32
DESCRIPTION
1.1 OVERVIEW
N116BGE-L32 is a 11.6” (11.6” diagonal) TFT Liquid Crystal Display module with LED Backlight unit and 40 pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The optimum viewing angle is at 6 o’clock direction.
1.2 GENERAL SPECIFICATI0NS
Item
Specification
Unit
Note
Screen Size
11.6 diagonal
Driver Element a-si TFT active matrix
- -
Pixel Number
1366 x R.G.B. x 768 pixel
- Pixel Pitch
0.1875 (H) x 0.1875 (V) mm
- Pixel Arrangement
RGB vertical stripe
- -
Display Colors
262,144 color
- Transmissive Mode
Normally white
- -
Surface Treatment
Hard coating (3H), Anti-Glare
- -
Luminance, White Power Consumption
200(typ.) Total 2.498 W (Max.) @ cell 0.686 W (Max.), BL 1.812 W (Max.)
Cd/m2 (1)
Note (1) The specified power consumption (with converter efficiency) is under the conditions at VCCS =
3.3 V, fv = 60 Hz, LED_VCCS = Typ, f PWM = 200 Hz, Duty=100% and Ta = 25 ± 2 ºC, whereas...
