JW3651 - 21V 3A 4-Switch Buck-Boost Converter

General Description

The JW®3651 is a high performance buck boost converter that the output voltage can be programmable from 0.9V up to 20V through external resistor.

Key Features

  • Integrate low RDS (on) power MOSFET.
  • Wide VINrange:3.0V-21V.
  • Wide VO range:0.9V-20V.
  • Compatible with 4-switch buck-boost mode and 2-switch boost mode.
  • Fixed frequency 450kHz.
  • Programmable input and output current limit.
  • Output constant current control.
  • Quiescent current:.

📥 Download Datasheet

Datasheet Details

Part number JW3651
Manufacturer JoulWatt
File Size 1.12 MB
Description 21V 3A 4-Switch Buck-Boost Converter
Datasheet download datasheet JW3651 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
JW3816A high current boost controller Juwell

Other Datasheets by JoulWatt

Part Number Description
JW3655 Multi-Cells Li-Ion Battery Charger
JW3655-1 Multi-Cells Li-Ion Battery Charger
JW3655E 3A Multi-Cells Li-Ion Battery Charger
JW3312 Battery Protection
JW3313 3 Series Battery Protector

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
JW3651 Parameters Subject to Change Without Notice DESCRIPTION The JW®3651 is a high performance buck boost converter that the output voltage can be programmable from 0.9V up to 20V through external resistor. The JW3651 implements the Buck Boost converter with a single inductor architecture that operates with input voltages above, below or equal to the output voltage. And support 2-switch boost mode for higher efficiency. The integrated low Rds(on) MOSFET minimizes physical footprint, maximizes efficiency, which reduces the power dissipation. Constant current control is utilized to protect the device from overshooting at fault conditions. Built-in loop compensation simplifies the circuit and design.
