JW5510 - 20V 10A Fully-integrated Synchronous Boost Converter

General Description

The JW®5510 is a highly integrated Boost converter and can be widely used in portable applications.

The JW5510 implements a synchronous high-efficiency step-up boost converter with 10A switch current capability and is capable of providing an output voltage up to 20V.

Key Features

  • 3.0V to 20V input voltage range 4.0V to 20V output voltage range Integrate Low RDSON Switch Power MOS and Synchronous Rectifier MOS. 10A Switch Current Limit Switch Frequency: 500kHz. High Efficiency over Full Load Range Thermal Shutdown QFN3.
  • 4 package.

📥 Download Datasheet

Datasheet Details

Part number JW5510
Manufacturer JoulWatt
File Size 1.01 MB
Description 20V 10A Fully-integrated Synchronous Boost Converter
Datasheet download datasheet JW5510 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
JW5026 16 Constant Current LED Driver RISETEK

Other Datasheets by JoulWatt

Part Number Description
JW5520S Synchronous Step-up Boost Converter
JW5015 40V Synchronous Rectified Step-Down Converter
JW5015A 2A 40V Synchronous Step-Down Converter
JW5015B 40V Synchronous Step-Down Converter
JW5017S 26V Synchronous Step-Down Converter

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
JW5510 Parameters Subject to Change Without Notice 20V 10A Fully-integrated Synchronous Boost Converter DESCRIPTION The JW®5510 is a highly integrated Boost converter and can be widely used in portable applications. The JW5510 implements a synchronous high-efficiency step-up boost converter with 10A switch current capability and is capable of providing an output voltage up to 20V. The integrated low Rds(on) MOSFET minimizes physical footprint, maximizes the efficiency, which reduces the power dissipation. Constant current control is utilized to protect the device from overshooting in unwanted conditions. Built-in loop compensation simplifies the circuit and design. PFM is engaged to maintain high efficiency at light load.
