1N4148W
1N4148W is Switching Diodes manufactured by Kexin Semiconductor.
Features
- Fast Switching Speed
- For General Purpose Switching Applications.
- High Conductance
- Surface Mount Package Ideally Suited for Automatic Insertion
SOD-123
2.7 +0.1 -0.1
Unit: mm 1.1 +0.05
-0.05
3.7 +0.1 -0.1
0.1max
+0.05 0.1 -0.02
- Absolute Maximum Ratings Ta = 25℃
Parameter Reverse Voltage Peak Repetitive Peak Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Average Rectified Output Current Forward Continuous Current Peak Forward Surge Current @ t=1us
@ t =1s Power Dissipation Thermal Resistance Junction to Ambient Junction Temperature Storage Temperature range
Symbol VRM VRRM VRWM VR
VR(RMS) IO IFM
IFSM
Pd RθJA
TJ Tstg
Rating 100
71 150 300
2 1 500 250 150 -55 to 150
- Electrical Characteristics Ta = 25℃
Parameter
Symbol
Test Conditions
Reverse breakdown voltage
VR IR= 100 u A
VF1 IF= 1m A
Forward voltage
VF2 IF= 10 m A VF3 IF= 50 m A
VF4 IF= 150 m A
Reverse voltage leakage current
IR1 VR= 75 V IR2 VR=20 V
Junction capacitance
Cj VR= 0 V, f= 1...
