Features posed of 2 independent diodes. Low forward voltage: VF (3) = 0.54V (typ.) Low reverse current: IR = 5 A (max) SOT-343 Unit: mm Absolute Maxim um Ratings Ta = 25 Param eter Maxim um (peak) reverse voltage Reverse voltage Maxim um (peak) forward current Average forward current Surge current (10 m s) Power dissipation Junction tem perature Storage tem perature range Operating tem perature range Note 1.Unit Rating.Total Rating = Unit Rating 1.5 Sym bol VR M VR IFM IO IFSM P Tj T stg Topr Rating 85 80 300(1) 100(1) 2(1) 150 125 -55 to +125 -40 to +100 Unit V V m A m A A m W Electrical Characteristics Ta = 25 Param eter Forward voltage Reverse current Total capacitance Sym bol V F (1) V F (2) V F (3) IR CT Conditions IF = 1 m A IF = 10 m A IF = 100 m A VR = 40 V VR=0 V,f=1 MHz M in Typ Max Unit A p F Marking Marking A4 .kexin..cn...
