AO4588 - N-Channel MOSFET

Key Features

  • s.
  • VDS (V) = 30V.
  • ID = 20 A (VGS = 10V).
  • RDS(ON) ＜ 4.8mΩ (VGS = 10V).
  • RDS(ON) ＜ 6.2mΩ (VGS = 4.5V).
  • ESD Rating: 2KV HBM +0.04 0.21 -0.02 SOP-8 D MOSFET Unit:mm 1.50 0.15 1 Source 2 Source 3 Source 4 Gate 5 Drain 6 Drain 7 Drain 8 Drain G S.
  • Absolute Maximum Ratings Ta = 25℃ Drain-Source Voltage Gate-Source Voltage Parameter Continuous Drain Current Pulsed Drain Current Avalanche Current TA=25℃ TA=70℃ Avalanche Energy L=0.1mH Power Dissipation Therma.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
AO4588 30V N-Channel MOSFET Freescale
AO4588 30V N-Channel MOSFET Alpha & Omega Semiconductors
AO4566 30V N-Channel MOSFET Alpha & Omega Semiconductors
AO4568 30V N-Channel AlphaMOS Alpha & Omega Semiconductors
AO4576 30V N-Channel AlphaMOS Freescale

Other Datasheets by Kexin Semiconductor

Part Number Description
AO4566 N-Channel MOSFET
AO4568 N-Channel MOSFET
AO4576 N-Channel MOSFET
AO4578 N-Channel MOSFET
AO4202 N-Channel MOSFET

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
SMD Type N-Channel MOSFET AO4588 (KO4588) ■ Features ● VDS (V) = 30V ● ID = 20 A (VGS = 10V) ● RDS(ON) ＜ 4.8mΩ (VGS = 10V) ● RDS(ON) ＜ 6.2mΩ (VGS = 4.5V) ● ESD Rating: 2KV HBM +0.04 0.21 -0.02 SOP-8 D MOSFET Unit:mm 1.50 0.15 1 Source 2 Source 3 Source 4 Gate 5 Drain 6 Drain 7 Drain 8 Drain G S ■ Absolute Maximum Ratings Ta = 25℃ Drain-Source Voltage Gate-Source Voltage Parameter Continuous Drain Current Pulsed Drain Current Avalanche Current TA=25℃ TA=70℃ Avalanche Energy L=0.1mH Power Dissipation Thermal Resistance.Junction- to-Ambient Thermal Resistance.Junction- to-Lead Junction Temperature Storage Temperature Range TA=25℃ TA=70℃ t ≤ 10s Steady-State Symbol VDS VGS ID IDM IAS,IAR EAS,EAR PD RthJA RthJL TJ Tstg Rating 30 ±20 20 15.5 140 45 101 3.
