Datasheet Summary
SMD Type
N-Channel MOSFET AO4706 (KO4706)
- Features
- VDS (V) = 30V
- ID = 16.5 A (VGS = 10V)
- RDS(ON) ＜ 6.8mΩ (VGS = 10V)
- RDS(ON) ＜ 8.2mΩ (VGS = 4.5V)
- SRFETTM Soft Recovery MOSFET:Integrated Schottky Diode
+0.04 0.21 -0.02
SOP-8
MOSFET
Unit:mm
1.50 0.15
1 Source 2 Source 3 Source 4 Gate
5 Drain 6 Drain 7 Drain 8 Drain
-...
