AON6516 - N-Channel MOSFET

Key Features

  • s.
  • VDS (V) = 30 V.
  • IDMAX (at VGS = 10 V) = 32 A.
  • RDS(ON) (at VGS = 10 V) < 5 mΩ.
  • RDS(ON) (at VGS = 4.5 V) < 8 mΩ.
  • Low Gate Charge.
  • High Current Capability S S S G DFN5x6-8(PDFNWB5x6-8L) D D D D.
  • Absolute Maximum Ratings (TA = 25℃ unless otherwise noted) Drain-Source Voltage Gate-Source Voltage Parameter Continuous Drain Current G Pulsed Drain Current C Continuous Drain Current Avalanche Current C Avalanche Energy L = 0.05 mH C VDS Spike Power D.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
AON6516 N-Channel MOSFET Alpha & Omega Semiconductors
AON6510 30V N-Channel MOSFET Alpha & Omega Semiconductors
AON6512 30V N-Channel MOSFET Alpha & Omega Semiconductors
AON6514 30V N-Channel MOSFET Alpha & Omega Semiconductors
AON6500 N-Channel MOSFET Alpha & Omega Semiconductors

Other Datasheets by Kexin Semiconductor

Part Number Description
AON6512 N-Channel MOSFET

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
SMD Type N-Channel MOSFET AON6516 (KON6516) TraMnOsiSsFtoErsT ■ Features ● VDS (V) = 30 V ● IDMAX (at VGS = 10 V) = 32 A ● RDS(ON) (at VGS = 10 V) < 5 mΩ ● RDS(ON) (at VGS = 4.5 V) < 8 mΩ ● Low Gate Charge ● High Current Capability S S S G DFN5x6-8(PDFNWB5x6-8L) D D D D ■ Absolute Maximum Ratings (TA = 25℃ unless otherwise noted) Drain-Source Voltage Gate-Source Voltage Parameter Continuous Drain Current G Pulsed Drain Current C Continuous Drain Current Avalanche Current C Avalanche Energy L = 0.05 mH C VDS Spike Power Dissipation B Power Dissipation A Thermal Resistance.Junction- to-Ambient A Thermal Resistance.Junction- to-Ambient A D Thermal Resistance.
