BAP64-05 Datasheet PDF

FEATURES

High voltage, current controlled RF resistor for RF attenuators and switches Low diode capacitance Low diode forward resistance Low series inductance For applications up to 3 GHz. +0.1 2.4 -0.1 SOT-23 2.9+0.1 -0.1 0.4+0.1 -0.1 3 1 2 0.95+0.1 -0.1 1.9+0.1 -0.1

ABSOLUTE MAXIMUM RATINGS

Ta = 25 Parameter Symbol Min Max Unit continuous reverse voltage VR 175 V continuous forward current IF 100 mA total power dissipation Ts = 90 Ptot 250 mW storage temperature Tstg -65 +150 junction temperature Tj -65 +150 thermal resistance from junction to soldering point Rth j-s 220 K/W 0-0.1 +0.1 0.38 -0.1 +0.1 1.3 -0.1 +0.1 0.97 -0.1 0.55 0.4 Unit: mm 0.1+0.05 -0.01 1.Base 2.Emitter 3.collector

ELECTRICAL CHARACTERISTICS

Ta = 25 Parameter Symbol Conditions Min Typ Max Unit forward voltage VF IF = 50 mA 0.95 1.1 V reverse leakage current VR VR = 175 V VR = 20 V 10 A 1 A VR = 0; f = 1 MHz 0.52 diode capacitance Cd VR = 1 V; f = 1 MHz 0.37 0.5 pF VR = 20 V; f = 1 MHz 0.23 0.35 IF = 0.5 mA; f = 10...
