BAT17 Datasheet PDF

FEATURES

Low forward voltage Small SMD package Low capacitance. +0.1 2.4 -0.1 SOT-23 2.9+0.1 -0.1 0.4+0.1 -0.1 3 1 2 0.95+0.1 -0.1 1.9+0.1 -0.1

ABSOLUTE MAXIMUM RATINGS

Ta = 25 Parameter Continuous reverse voltage Continuous forward current Storage temperature Junction temperature thermal resistance from junction to ambient Symbol VR IF Tstg Tj Rth j-a Min -65 Max 4 30 +150 100 500 Unit V mA K/W 0-0.1 +0.1 0.38 -0.1 +0.1 1.3 -0.1 +0.1 0.97 -0.1 0.55 0.4 Unit: mm 0.1+0.05 -0.01 1.Base 2.Emitter 3.collector

ELECTRICAL CHARACTERISTICS

Ta = 25 P aram eter S ym bol C o n d itio n s Max U n it IF =0.1 mA 350 Forward voltage VF IF = 1 mA 450 mV IF = 10 mA 600 Reverse current VR = 3 V IR VR = 3 V; Tamb = 60 0.25 A 1.25 Diode forward resistance rD f = 1 KHz; IF = 5 mA 15 Diode capacitance Cd f = 1 MHz; VR = 0 1 pF noise figure F f = 900 MHz; Note 1 8 dB N o te 1. The local oscillator is adjusted for a diode current of 2 m A. IF am plifier noise Fif = 1.5 dB; f = 35 M Hz. Marking Marking A3p 1
