FMG3A Datasheet Dual Digital Transistors

Manufacturer: Kexin Semiconductor

Overview: SMD Type TransistIoCrs Emitter common (Dual Digital Transistors) FMG3A.

FMG3A datasheet preview

Datasheet Details

Part number	FMG3A
Manufacturer	Kexin Semiconductor
File Size	132.13 KB
Description	Dual Digital Transistors
Datasheet	FMG3A-Kexin.pdf

Key Features

s.
Dual NPN digital transistor 5 4 1 2 3 (3) (2) (1) R1=4.7kΩ R1 R1 DTr2 DTr1 (4) (5) Unit: mm.
Absolute Maximum Ratings Ta = 25℃ Parameter Symbol Rating Unit Collector-base voltage VCBO 50 V Collector-emitter voltage VCEO 50 V Emitter-base voltage VEBO 5 V Collector current IC 100 mA Power dissipation(Total) Pd 300 mW Operating and Storage and Temperature Range Tj, TSTG -55 to +150 ℃.
Electrical Characteristics Ta = 25℃ Parameter Colle.
