1) Two DTC143T chips in a EMT or UMT or SMT package. 2) Mounting cost and area can be cut in half. zExternal dimensions (Unit : mm)
EMG3
0.5 0.5 1.0 1.6
0.22
(4)
(3) (2)
(5)
zStructure Dual NPN digital transistor (each with a single built in resistors)
ROHM : EMT5
0.13
1.2 1.6
(1)
Each lead has same dimensions
Abbreviated symbol : G3
(4)
(3)
The following characteristics apply to both the DTr1 and DTr2.
UMG3N
0.65 0.65 1.3 0.2 2.0
(2) (5)
zEquivalent circuit
0.15
1.25 2.1
(1).
The following content is an automatically extracted verbatim text
from the original manufacturer datasheet and is provided for reference purposes only.
View original datasheet text
EMG3 / UMG3N / FMG3A
Transistors
Emitter common (dual digital transistors)
EMG3 / UMG3N / FMG3A
zFeatures 1) Two DTC143T chips in a EMT or UMT or SMT package. 2) Mounting cost and area can be cut in half.
zExternal dimensions (Unit : mm)
EMG3
0.5 0.5 1.0 1.6
0.22
(4)
(3) (2)
(5)
zStructure Dual NPN digital transistor (each with a single built in resistors)
ROHM : EMT5
0.13
1.2 1.6
(1)
Each lead has same dimensions
Abbreviated symbol : G3
(4)
(3)
The following characteristics apply to both the DTr1 and DTr2.
UMG3N
0.65 0.65 1.3 0.2 2.0
(2) (5)
zEquivalent circuit
0.15
1.25 2.1
(1)
0.5
0to0.1
EMG3 / UMG3N
(3) R1 DTr2 (4) (2) (1) R1=4.7kΩ R1 DTr1 (5)
FMG3A
(3) R1 DTr2 (2) (4) (5) R1=4.7kΩ R1 DTr1 (1)
0.1Min.
FMG3A Datasheet
