FMY1A Datasheet Dual Transistors

Manufacturer: Kexin Semiconductor

Overview: SMD Type TransistIoCrs Emitter mon (Dual Transistors) FMY1A ■.

Datasheet Details

s.
PNP and NPN transistors have common emitters.
Mounting cost and area can be cut in half. (3) (2) (1) R1 Tr2 Tr1 (4) (5) 5 4 1 2 3 Unit: mm.
Absolute Maximum Ratings Ta = 25℃ Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector current Power dissipation(Total) Operating and Storage and Temperature Range Symbol VCBO VCEO VEBO IC PD Tj, TSTG Rating Unit Tr1 Tr2 -60 60 V -50 50 V -6 7 V -150 150 mA 300 mW -55 to.
