FTD2019 - Dual N-Channel Enhancement Mode MOSFET

Key Features

  • s.
  • RDS(ON)=28mΩ Max. @VGS=4V.
  • RDS(ON)=35mΩ Max. @VGS=2.5V D1 S1 S1 D1 TSSOP-8 Unit: mm 1 : Drain1 2 : Source1 3 : Source1 D2 4 : Gate1 S2 5 : Gate2 6 : Source2 S2 7 : Source2 G2 8 : Drain2.
  • Absolute Maximum Ratings Ta = 25℃ Parameter Drain-Source Voltage Gate-Source Voltage Drain-Current -Continuous -Pulsed (NOTE 1) Power Dissipation (NOTE 2) Thermal Resistance,Junction- to-Ambient Operating Junction and Storage Temperature Range Note: 1. PW≤10μs, duty c.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
FTD2019 N-Channel MOSFET Sanyo Semicon Device
FTD2019 30V Dual N-Channel MOSFET VBsemi
FTD2019A N-Channel MOSFET Sanyo
FTD2011 N-Channel MOSFET Sanyo Semicon Device
FTD2011 25V Dual N-Channel MOSFET VBsemi

Other Datasheets by Kexin Semiconductor

Part Number Description
FTD2011 Dual N-Channel Enhancement Mode MOSFET

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
SMD Type Transistors Dual N-Channel Enhancement Mode MOSFET FTD2019 ■ Features ● RDS(ON)=28mΩ Max. @VGS=4V ● RDS(ON)=35mΩ Max. @VGS=2.5V D1 S1 S1 D1 TSSOP-8 Unit: mm 1 : Drain1 2 : Source1 3 : Source1 D2 4 : Gate1 S2 5 : Gate2 6 : Source2 S2 7 : Source2 G2 8 : Drain2 ■ Absolute Maximum Ratings Ta = 25℃ Parameter Drain-Source Voltage Gate-Source Voltage Drain-Current -Continuous -Pulsed (NOTE 1) Power Dissipation (NOTE 2) Thermal Resistance,Junction- to-Ambient Operating Junction and Storage Temperature Range Note: 1. PW≤10μs, duty cycle≤1% 2. Mounted on a ceramic board (1000mm2×0.8mm) Symbol VDS VGS ID IDM PD RθJA Tj.Tstg Rating 30 ±10 5 20 1.3 96 -55 to 150 Unit V V A A W ℃/W ℃ 1 www.kexin.com.
