MMBT4403
MMBT4403 is PNP Transistors manufactured by Kexin Semiconductor.
Features
ƽ Ideal for Medium Power Amplification and Switching ƽ plementary NPN Type Available (MMBT4401)
SOT-23
2.9 +0.1 -0.1
0.4 +0.1 -0.1
Unit: mm
+0.1 1.3 -0.1
+0.1 2.4 -0.1
0.95 +0.1 -0.1 1.9 +0.1 -0.1
0.1 +0.05 -0.01
+0.1 0.97 -0.1
Ƶ Absolute Maximum Ratings Ta = 25ć
Parameter Collector
- Base Voltage Collector
- Emitter Voltage Emitter
- Base Voltage Collector Current Total Device Dissipation Alumina Substrate Thermal Resistance Junction to Ambient Junction Temperature Storage Temperature range
Symbol VCBO VCEO VEBO IC PD RșJA TJ Tstg
Rating -40 -40 -5 -600 300 417 150
-55 to +150
Unit
V m A m W ć/W ć
0-0.1 +0.1 0.38
-0.1
1.Base 2.Emitter 3.collector
Ƶ Electrical Characteristics Ta = 25ć
Parameter
Symbol
Test Conditions
Min Typ Max Unit
Collector- base breakdown voltage
VCBO Ic= -100 ȝAˈ IE=0
-40
Collector- emitter breakdown voltage
VCEO Ic= -1.0 m Aˈ...
