Datasheet Summary
SMD Type
Transistors
NPN Transistor PBSS2515E
Ƶ Features
ƽ Low collector-emitter saturation voltage VCEsat ƽ High collector current capability IC and ICM ƽ High collector current gain (hFE) at high IC ƽ High efficiency due to less heat generation ƽ Reduced printed-circuit board area requirements
SC-75
1.75 0.9 1.45 0.7
1.8 1.4
Unit: mm
0.95 0.60
0.45 0.15
1 1
3 1
1.Base 2.Emitter 3.collector
Ƶ...
