LBSS139WT1G
FEATURES
- We declare that the material of product pliance with Ro HS requirements and Halogen Free.
- Low threshold voltage (VGS(th): 0 1.5V) makes it ideal for low voltage applications.
- ESD Protected:1500V
- MSL:Level 1
2. DEVICE MARKING AND ORDERING INFORMATION
Device
Marking
Shipping
J2
3000/Tape&Reel
LBSS139WT3G
J2
13000/Tape&Reel
3. MAXIMUM RATINGS(Ta = 25ºC)
Parameter
Symbol Limits Unit
Drain- Source Voltage
VDSS
Gate- to- Source Voltage
- Continuous VGS
±20
Drain Current m A
- Continuous TA = 25°C
- Pulsed (tp≤10μs)
4. THERMAL CHARACTERISTICS
Parameter
Symbol
Total Device Dissipation,
FR- 4 Board (Note 1) @ TA = 25ºC
Derate above 25ºC
Thermal Resistance,
RΘJA
Junction- to- Ambient(Note 1)
Junction and Storage...
