HT7533 Description
The HT75XX series are highly accurate, LDO Voltage Regulators that are manufactSu1reD2d using CMOS technology and the input voltagDe1of HT75XX series is in Excess of 30V.
HT7533 Key Features
- Low Quiescent Current：2.5uA
- High Input Voltage Rating：Up to 30V
- Low voltage drop
- Fixed Output Voltages：
- High-accuracy Output Voltage: ±2%
- Fast Transient Response
- Over current protection
- Battery-powered equipment
- Smoke detector and sensor
- Micro controller
