KTC4075 Datasheet | MLS Microelectronics

Features - Excellent h FE linearity - High h FE - Low Noise - plementary to KTA2014 Transistor (NPN) C LO/LY/LGR/LBL SOT-23 top view Schematic diagram Marking and pin assignment Maximum Ratings (Ta=25℃ unless otherwise noted) Symbol Parameter Value Unit VCBO VCEO VEBO Ic Pc TJ , TSTG Collector-Base Voltage Collector-Emitter Voltage Emitter-Base Voltage Collector Current Collector Power Dissipation Operating and Storage Temperature Range 150 m A 100 m W -55～+150 ℃ Electrical Characteristics (Ta=25℃ unless otherwise specified) Symbol Parameter V(BR)CBO V(BR)CEO V(BR)EBO ICBO IEBO h FE VCE(sat) f T Cob Collector-base breakdown voltage Collector-emitter breakdown voltage Emitter-base breakdown voltage Collector cut-off current Emitter cut-off current DC current gain Collector-emitter saturation voltage Transition frequency Collector output capacitance Noise Figure Test conditions IC=100μA,IE=0 IC=1m A,IB=0 IE=100μA,IC=0 VCB=60V,IE=0 VEB=5V,IC=0 VCE=6V,IC=2m A IC=100m A IB=10m A VCE= 10V, Ic=1m A VCB=10V,IE=0,f=1MHz VCE=6V,IE=0.1m A, f=1KHz,RG=10KΩ Min 60 50 5 --70 -80 -- Max ---0.1 0.1 700 0.25 -3.5 Unit V V V μA μA V MHz p...
