Features - High density cell design for ultra low RDS(ON) - Fully characterized avalanche voltage and current - Excellent package for good heat dissipation Application - High current load applications - Load switch - Hard switched and high frequency circuits DD D D MLSM XXXX ME0D90A: Device code XXXX: Code 30V/90A N-Channel MOSFET Product Summary RDS(ON) TYP 30V 2.2mΩ@1S10VD2 3.3mΩD@1 4.5V 90A PDFN3X3-8L view Schematic diagram SS S G Marking and pin assignment Absolute Maximum Ratings (TA=25℃unless otherwise noted) Symbol Parameter mon Ratings (TC=25°C Unless Otherwise Noted) Drain-Source Breakdown Voltage Gate-Source Voltage Maximum Junction Temperature TSTG Storage Temperature Range Diode Continuous Forward Current Mounted on Large Heat Sink Pulse Drain Current...
