MT0E16A Datasheet | MLS Microelectronics

Features - High density cell design for ultra low RDS(ON) - Fully characterized avalanche voltage and current - Good stability and uniformity with high EAS - Excellent package for good heat dissipation Application - Power switching application 40V/16A N-Channel MOSFET Product Summary RDS(ON) TYP 40V 6.5mΩ@1S10VD2 16A 7.8mΩD@1 4.5V 0E16A MLSM XXXX 0E16A : Device code XXXX : Code SOT-223 top view Schematic diagram Marking and pin assignment Absolute Maximum Ratings (TA=25℃unless otherwise noted) Symbol Parameter mon Ratings (TC=25°C Unless Otherwise Noted) Drain-Source Breakdown Voltage Gate-Source Voltage Maximum Junction Temperature TSTG Storage Temperature Range Diode Continuous Forward Current Mounted on Large Heat...
