Datasheet Details
| Part number | MCP1700 |
|---|---|
| Manufacturer | Microchip Technology |
| File Size | 1.24 MB |
| Description | Low Quiescent Current LDO |
| Datasheet | MCP1700_MicrochipTechnology.pdf |
|
|
Overview: MCP1700 Low Quiescent Current LDO.
| Part number | MCP1700 |
|---|---|
| Manufacturer | Microchip Technology |
| File Size | 1.24 MB |
| Description | Low Quiescent Current LDO |
| Datasheet | MCP1700_MicrochipTechnology.pdf |
|
|
|
The MCP1700 is a family of CMOS low dropout (LDO) voltage regulators that can deliver up to 250 mA of current while consuming only 1.6 µA of quiescent current (typical).
The input operating range is specified from 2.3V to 6.0V, making it an ideal choice for two and three primary cell battery-powered applications, as well as single cell Li-Ion-powered applications.
The MCP1700 is capable of delivering 250 mA with only 178 mV of input to output voltage differential (VOUT = 2.8V).
