PIC16F84A Datasheet 18-pin Enhanced Flash/eeprom 8-bit Microcontroller

Manufacturer: Microchip Technology

Overview: PIC16F84A 18-pin Enhanced FLASH/EEPROM 8-Bit Microcontroller High Performance RISC.

PIC16F84A datasheet preview

Datasheet Details

Part number	PIC16F84A
Manufacturer	Microchip Technology
File Size	1.08 MB
Description	18-pin Enhanced Flash/EEPROM 8-Bit Microcontroller
Datasheet	PIC16F84A_MicrochipTechnology.pdf

Key Features

Only 35 single word instructions to learn.
All instructions single-cycle except for program branches which are two-cycle.
Operating speed: DC - 20 MHz clock input DC - 200 ns instruction cycle.
1024 words of program memory.
68 bytes of Data RAM.
64 bytes of Data EEPROM.
14-bit wide instruction words.
8-bit wide data bytes.
15 Special Function Hardware registers.
Eight-level deep hardware stack.
