.. Order this document by MPC823ELE/D Revision 1
MPC823 AC Electrical Specifications
This document contains detailed information on power considerations, DC/AC electrical characteristics, and AC timing specifications for the MPC823. Note: Visit our website at .motorola. if you are using a frequency other than 25, 40, or 50MHz. Our website contains a spreadsheet that you can use to calculate the timing for your specific system frequency.
This device contains circuitry protecting against damage from high-static voltage or electrical fields. However, it is advised that precautions be taken to avoid application of any voltages higher than the maximum-rated voltages to...
