NSI7258-Q1 Description
NSI7258-Q1 1700-V 50mA Solid-State Relay Datasheet (EN) 1.0 Product Overview The NSI7258-Q1 is a single-channel solid-state relay (SSR), which is pin-patible for popular photo MOSFET. The SSR turns ON with a minimum input current of 5.5mA. It can conduct 30mA current at ON state, with resistance less than 250Ω.
NSI7258-Q1 Key Features
- AEC Q-100 Qualified for Grade 1: TA from -40 °C to 125 °C
- Normally open (1-Form-A) solid state relay
- Up to 5000Vrms Insulation voltage
- Breakdown voltage: 1700V
- OFF state leakage current: <1μA at 1000V
- ON state resistance: <250Ω at 10mA load current
- Input forward threshold current: <5.5mA
- Turn on time: <0.3ms
- Turn off time: <0.05ms
- RoHS-pliant Packages: SOW12
