NSPAD1N Datasheet | NOVOSENSE

Overview NSPAD1N is a calibrated absolute pressure sensor series product launched by NOVOSENSE which uses an automotive grade ASIC to calibrate and pensate the MEMS sensor element. The pressure signal from 10k Pa to 400k Pa can be converted into SPI/I2C output signal or analog output signal (0~5V) with a customizable output range. While ensuring the reliability of the product, the two chips are integrated and packaged, reduces the package size greatly. This series provides outstanding performance in terms of high initial accuracy and small drift over lifetime. Applications - Automotive seat fort system - Automotive barometric absolute pressure (ECU-BAP) - Industrial control Device Information Part Number Package Body Size DFN-8 3mm × 3mm × 1.54mm Key Features - High precision pressure sensing Digital output better than ±1%F.S. (-20°C to 115°C) Analog output better than ±1.5%F.S. (-20°C to 115°C) - Large temperature range (-40°C to 125°C) - Pressure range can be customized - 24-bit ADC and 12-bit DAC - I2C/SPI/Analog output - Surface-mountable DFN-8 package with Wettable Flank - AEC-Q100 qualified - Ro HS & REACH pliance - Moisture sensitivity level: MSL1 Outline Copyright © 2025, NOVOSENSE Page 1 NSPAD1N Series Datasheet (EN) 1.0 INDEX 1. PIN CONFIGURATION AND FUNCTIONS 3 2. ABSOLUTE MAXIMUM RATINGS 4 3. ESD RATINGS 4 4. REMENDED OPERATING CONDITIONS 4 5. SPECIFICATIONS...
