NJM555M Datasheet TIMER

Manufacturer: New Japan Radio

Download the NJM555M datasheet PDF. This datasheet also includes the NJM555 variant, as both parts are published together in a single manufacturer document.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (NJM555_NewJapanRadio.pdf) that lists specifications for multiple related part numbers.

General Description

The NJM555 monolithic timing circuit is a highly stable controller capable of producing accruate time delays or oscillation.

In the time delay mode, delay time is precisely controlled by only two external parts : a resistor and a capacitor.

For operation as an oscillator, both the free running frequency and the duty cycle are accurately controlled by two external resistors and a capacitor.

Overview

NJM555 TIMER ■ GENERAL.

Key Features

  • S.
  • Operating Voltage (4.5V to 16V).
  • Less Number of External Components.
  • Package Outline DIP8, DMP8, SSOP8, SIP8.
  • Bipolar Technology NJM555L NJM555V.
  • PIN.
