FS8K Description
The FS8G to FS8M series offers breakthrough size and performance. It sinks 8 A DC forward current and provides up to 230 A surge current capability with only 0.37 mA reverse leakage current. All this capability is packed into a small, flat−lead, TO−277 package, optimized for space−constrained applications.
FS8K Key Features
- Very High forward Surge Capability: IFSM = 230 A
- Low Leakage Current: 0.37 mA at TA = 25°C
- Very Low Profile: Typical Height of 1.1 mm
- Glass Passivated Junction
- HBM (JEDEC A114) > 8 KV; CDM (JEDEC C101C) > 2 KV
- Green Molding pound as per IEC61249 Standard
- With DAP Option Only
- These Devices are Pb-Free, Halogen Free Free and are RoHS
