MBRD1035CTL
MBRD1035CTL is Switch-mode Schottky Power Rectifier manufactured by onsemi.
DATA SHEET .onsemi.
Switch-mode Schottky Power Rectifier
DPAK Power Surface Mount Package
MBRD1035CTL, NRVBD1035VCTL, SBRD81035CTL Series
The MBRD1035CTL employs the Schottky Barrier principle in a large area metal-to-silicon power diode. State of the art geometry Features epitaxial construction with oxide passivation and metal overlay contact. Ideally suited for low voltage, high frequency switching power supplies, free wheeling diode and polarity protection diodes.
Features
- Highly Stable Oxide Passivated Junction
- Guardring for Stress Protection
- Matched Dual Die Construction-
May be Paralleled for High Current Output
- High dv/dt Capability
- Short Heat Sink Tap Manufactured-No...
